Battery Type	MBYZ16UHD
Voltage	12
CCA	260
MCA	308A
PHCA	487A
Capacity (10HR)	16.5Ah, C20 17.5Ah
Weight	5.05kg /11.13Ibs
Dimensions (in / mm)	L: 5.94(151) W: 3.43(87) H: 5.71(145)
Assembly Figure Terminal Locations	4
Terminals	2x Blocknut M6 (PART MPN2)
Screws	2x Screws M6x12 (PART MPS4)
Terminal Caps	4, 12x5.5 (Part#2xMPC2)

⚫ Patented Quad Terminal Design-Reduce carrying costs
⚫ 12V VRLA Hi Capacity Starting Battery
⚫ Absorbed Glass Mat(AGM)technology
⚫ Brass Terminals- superior conductivity
⚫ US DOT, IATA certified non-spillable
⚫ Highest AH Capacity in the Industry
⚫ Factory Activated-ready to Install
Nominal Voltage --------------------------------------------------- 12 volts(6cells)
Nominal Capacity 25℃(77℉)
20-hr. (0.83A to 10.50 volts) ----------------------------------------------17.5AH
10-hr. (1.65A to 10.50 volts) ---------------------------------------------- 16.5AH
5-hr. (3.30A to 10.20 volts) ---------------------------------------------- 13.53AH
1C. (16.5A to 9.60 volts) -----------------------------------------------11.55AH
3C. (49.5A to 9.60 volts) -----------------------------------------------6.44AH
Approximate Weight ----------------------------------------11.13lbs. (5.05kg)
Energy Density ( 20-hr rate ) --------------------1.62W-h / in3 ( 98.7W-h/1 )
Specific Energy ( 20-hr rate ) --------------------17.6W-h / lb ( 38.8W-h/kg )
Internal Resistance ( approx ) -----------------------------------18 milliohms
CCA(-0 4℉/-18℃,7.2V,30S) -------------------------------------240 amperes
CA(32℉/0℃,7.2V,30S) --------------------------------------------308 amperes
Shelf Life (% of normal capacity at 68℉/20℃) --- SOC% OCV
1 months ----------------------------------------------------------- 97% 12.78V
3 months ----------------------------------------------------------- 91% 12.70V
6 months ------------------------------------------------------------ 83% 12.5V
Operating Temperature Range
Discharge ------------------------------------------ -4℉(-20℃) to 122℉(50℃)
Charge -------------------------------------------- -40℉(-40℃) to 140℉(60℃)
Case ------------------------------------------------------------------------- ABS
Length: 5.94in(151mm) Width: 3.43in(87mm)
Height: 5.70in(145mm)
Tolerances are ±0.04 inches (±1mm) and ±0.08
inches (±2mm) for height.
Features
Performance Specifications
MBYZ16HD
Terminal Dimensions (mm)
Physical Dimensions (in./mm)
SCREW
