Battery Type	MBTZ7S
Voltage	12
CCA	130
MCA	190
PHCA	360A
Capacity (10HR)	6.5Ah, C20 6.9Ah
Weight	2.10kg / 4.63Ibs
Dimensions (in / mm)	L: 4.49(114) W: 2.76(70) H: 4.21(107)
Assembly Figure Terminal Locations	2
Terminals	2x Screws M5x10 (PART MPS3) 2x Blocknut M5 (PART MPN1)

⚫ Patented Quad Terminal Design-Reduce carrying costs
⚫ 12V VRLA Hi Capacity Starting Battery
⚫ Absorbed Glass Mat(AGM)technology
⚫ Brass Terminals- superior conductivity
⚫ US DOT, IATA certified non-spillable
⚫ Highest AH Capacity in the Industry
⚫ Factory Activated-ready to Install
Nominal Voltage --------------------------------------------------- 12 volts(6cells)
Nominal Capacity 25℃(77℉)
20-hr. (0.33A to 10.50 volts) ---------------------------------------------- 6.90AH
10-hr. (0.65A to 10.50 volts) ---------------------------------------------- 6.50AH
5-hr. (1.30A to 10.20 volts) ---------------------------------------------- 5.33AH
1C. (6.50A to 9.60 volts) ------------------------------------------------4.55AH
3C. (19.5A to 9.60 volts) ----------------------------------------------- 2.54AH
Approximate Weight ---------------------------------------- 4.63lbs. (2.10kg)
Energy Density ( 20-hr rate ) --------------------1.62W-h / in3 ( 98.7W-h/1 )
Specific Energy ( 20-hr rate ) --------------------17.6W-h / lb ( 38.8W-h/kg )
Internal Resistance ( approx ) -----------------------------------18 milliohms
CCA(-0 4℉/-18℃,7.2V,30S) -------------------------------------100 amperes
CA(32℉/0℃,7.2V,30S) --------------------------------------------158 amperes
Shelf Life (% of normal capacity at 68℉/20℃) --- SOC% OCV
1 months ----------------------------------------------------------- 97% 12.78V
3 months ----------------------------------------------------------- 91% 12.70V
6 months ------------------------------------------------------------ 83% 12.5V
Operating Temperature Range
Discharge ------------------------------------------ -4℉(-20℃) to 122℉(50℃)
Charge -------------------------------------------- -40℉(-40℃) to 140℉(60℃)
Case ------------------------------------------------------------------------- ABS
Length: 4.49in(114mm) Width: 2.76in(70mm)
Height: 4.21in(107mm)
Tolerances are ±0.04 inches (±1mm) and ±0.08
inches (±2mm) for height.
Features
Performance Specifications
MBTZ7S
Terminal Dimensions (mm)
Physical Dimensions (in./mm)
SCREW
