Battery MotoBatt MBTX9U

Product image 1
1 / 3

Battery MotoBatt MBTX9U

Battery Type MBTX9U
Voltage 12
CCA 160
MCA 219A
PHCA 393A
Capacity (10HR) 10.5Ah, C20 11.1Ah
Weight 3.40kg / 7.50Ibs
Dimensions (in / mm) L: 5.94(151) W: 3.43(87) H: 4.13(110) TH:4.13(110)
Assembly Figure Terminal Locations 4
Terminals 2x Blocknut M6 (PART MPN2)
Screws 2x Screws M6x12 (PART MPS4)
Spacer 1, 5mm Bottom (Part#MPBS1)

WARNING: This product can expose you to chemicals including Sodium salt, Lead and Lead, Nickel (Metallic), which are known to the State of California to cause cancer or birth defects or other reproductive harm.
For more information,

⚫ Patented Quad Terminal Design-Reduce carrying costs
⚫ 12V VRLA Hi Capacity Starting Battery
⚫ Absorbed Glass Mat(AGM)technology
⚫ Brass Terminals- superior conductivity
⚫ US DOT, IATA certified non-spillable
⚫ Highest AH Capacity in the Industry
⚫ Factory Activated-ready to Install
Nominal Voltage --------------------------------------------------- 12 volts(6cells)
Nominal Capacity 25℃(77℉)
20-hr. (0.53A to 10.50 volts) ---------------------------------------------- 11.10AH
10-hr. (1.05A to 10.50 volts) ---------------------------------------------- 10.50AH
5-hr. (2.10A to 10.20 volts) ---------------------------------------------- 8.61AH
1C. (10.5A to 9.60 volts) ------------------------------------------------7.35AH
3C. (31.5A to 9.60 volts) ----------------------------------------------- 4.10AH
Approximate Weight ---------------------------------------- 7.50lbs. (3.40kg)
Energy Density ( 20-hr rate ) --------------------1.62W-h / in3 ( 98.7W-h/1 )
Specific Energy ( 20-hr rate ) --------------------17.6W-h / lb ( 38.8W-h/kg )
Internal Resistance ( approx ) -----------------------------------18 milliohms
CCA(-0 4℉/-18℃,7.2V,30S) -------------------------------------160 amperes
CA(32℉/0℃,7.2V,30S) --------------------------------------------195 amperes
Shelf Life (% of normal capacity at 68℉/20℃) --- SOC% OCV
1 months ----------------------------------------------------------- 97% 12.78V
3 months ----------------------------------------------------------- 91% 12.70V
6 months ------------------------------------------------------------ 83% 12.5V
Operating Temperature Range
Discharge ------------------------------------------ -4℉(-20℃) to 122℉(50℃)
Charge -------------------------------------------- -40℉(-40℃) to 140℉(60℃)
Case ------------------------------------------------------------------------- ABS
Length: 5.94in(151mm) Width: 3.43in(87mm)
Height: 4.13in(105mm)
Tolerances are ±0.04 inches (±1mm) and ±0.08
inches (±2mm) for height.
Features
Performance Specifications
MBTX9U
Terminal Dimensions (mm)
Physical Dimensions (in./mm)
SCREW
